Description
Classification Enclosure:
Type of material: Isolated , Halogen Free
Fixation Place: Wall
Environment: Interior/Exterior
Protection Degree: IP68
Impact Resistance: IK08
Isolated Tension: 1000 V
Dielectric Strength: 2.5 kV
Glow Wire: 650 °C
Isolated Rate: 90 °C
Dimensional Stability:
– Temperature: -25 °C / +85 °C
– Humidity: 100% HR
Build Characteristics:
– Clip-On Cover
– Inputs: 7 CONOS Ø 20 / 7 CONES Ø 20 mm
Characteristics of the gel:
– Insulation Gel
– Dry time:30 min.
– Not a hazardous substance or mixture according to
Regulation (EC) Nº 1272/2008
– 200ml Total= 100ml Comp. A + 100ml Comp. B
Standard: EN 60670.22
