Description
Classification Enclosure:
Type of material: Isolated , Halogen Free
Fixation Place: Wall
Environment: Interior/Exterior
Protection Degree: IP65
Impact Resistance: IK08
Isolated Tension: 1000 V
Dielectric Strength: 2.5 kV
Glow Wire: 650 °C
Isolated Rate: 90 °C (Thermic class 90, Y)
Power Loss: 11 W
Dimensional Stability:
– Temperature: -25 °C / +85 °C
– Humidity: 100% HR
Build Characteristics:
– Modules: 6
– Knock-Outs: 1
– Transparent Door
– DIN-Rail
– Allowable Load on the Doors: 1 Kg
– Caps for the Degree: IP65
– No Linkable
Standard: EN 62208
